Zadané hodnoty
| Ui [mV] |
Ii [mA] |
| 427 |
0.04 |
| 446 |
0.09 |
| 464 |
0.2 |
| 483 |
0.42 |
| 490 |
0.56 |
| 492 |
0.61 |
| 496 |
0.73 |
| 500 |
0.85 |
| 502 |
0.91 |
| 505 |
1.01 |
| 509 |
1.21 |
| 511 |
1.32 |
| 515 |
1.52 |
| 517 |
1.66 |
| 519 |
1.77 |
| 520 |
1.89 |
| 522 |
2 |
| 528 |
2.51 |
| 533 |
3.07 |
| 536 |
3.52 |
| 540 |
4 |
| 543 |
4.54 |
| 546 |
5.06 |
| 550 |
6.07 |
| 554 |
7.04 |
| 558 |
8.09 |
| 561 |
9.02 |
| 564 |
10.1 |
| 568 |
12.06 |
| 573 |
14.02 |
| 577 |
16.16 |
| 580 |
18.08 |
| 583 |
20.2 |
| t [o C] |
| 15.5 | |
Vypočtené hodnoty
 |
| I0 = 2.162E-12 A |
| k = 1.406E-23 J/K |
Pravděpodobné chyby
měřených konstant |
 I0
= 1.5E-13 A |
| k
= 4.7E-26 J/K | |
